NORDICTRACK ELITE 14.7 ELLIPTICAL – NTEL21412.3
Click on the part / diagram number to view and add to cart.
If the number does not highlight please check the table below the diagram to see if your part is listed. All parts in the table should have a corresponding diagram number. If your part is not listed at all please Click Here
148 Parts Available for NORDICTRACK ELITE 14.7 ELLIPTICAL - NTEL21412.3 ↓
| Image | Part # | Diagram # | Title | Price | Details | |
|---|---|---|---|---|---|---|
| 338264 | 2 | REAR STABILIZER COVER | $149.99 | |||
| 335150 | 3 | RAMP | $196.49 | |||
| 315996 | 8 | FRONT STABILIZER COVER | $119.99 | |||
| 306623 | 9 | BOTTOM RAMP COVER | $168.49 | |||
| 341892 | 11A | TRACK,W/TAPE | $111.49 | |||
| 336428 | 12 | LEFT ROLLER ARM | $168.49 | |||
| 317352 | 13 | LIFT MOTOR | $205.49 | |||
 | 264511 | 16 | POWER SWITCH | $32.99 | ||
 | 313668 | 17 | POWER CORD GROMMET | $9.49 | ||
| 339344 | 18 | CRANK | $133.49 | |||
| 277369 | 19 | PULLEY | $174.49 | |||
| 316047 | 21 | ROLLER ARM CAP | $11.99 | |||
 | 363093 | 22 | IDLER | $116.49 | ||
| 256183 | 23 | M3 X 8MM SCREW,NOTE: | $1.49 | |||
 | 193223 | 25 | RESISTANCE MOTOR | $99.99 | ||
| 333606 | 26 | SADDLE BRACKET | $4.99 | |||
| 317332 | 27 | INCLINE MOTOR BUSHING | $3.99 | |||
| 346384 | 28B | MECHANISM AXLE | $40.99 | |||
 | 321353 | 28C | RESISTANCE CABLE | $25.49 | ||
 | 143426 | 30 | UPRIGHT BUSHING | $8.99 | ||
| 317331 | 31 | MAGNET AXLE | $26.99 | |||
| 306636 | 32 | LIFT MOTOR SPACER | $3.49 | |||
| 306628 | 34 | WHEEL | $32.49 | |||
| 306648 | 35 | PIVOT AXLE | $106.99 | |||
| 306615 | 37 | ACCESSORY TRAY | $35.49 | |||
| 307218 | 38 | REED SWITCH/WIRE | $30.49 | |||
 | 131090 | 39 | REED SWITCH CLIP | $0.99 | ||
 | 295804 | 40 | FRAME BEARING | $66.99 | ||
| 338041 | 41A | RIGHT GRIP ASSY | $109.49 | |||
| 338252 | 41B | RIGHT GRIP WIRE | $82.99 | |||
 | 113842 | 43 | MAGNET | $1.49 | ||
| 334195 | 44 | LEFT PEDAL ARM | $199.49 | |||
| 336430 | 45 | RIGHT ROLLER ARM | $168.49 | |||
| 334953 | 46 | LEFT UPPER BODY LEG | $134.49 | |||
| 337991 | 47 | LEFT UPPER BODY ARM | $108.99 | |||
| 338035 | 48A | LEFT GRIP ASSY | $109.49 | |||
| 338251 | 48B | LEFT GRIP WIRE | $82.99 | |||
| 334972 | 49 | RIGHT PEDAL | $197.99 | |||
| 317937 | 50 | NYLON INSERT | $1.49 | |||
 | 306984 | 51 | PEDAL ARM ROLLER | $85.99 | ||
| 335148 | 52 | FAN GRILL | $106.99 | |||
| 333641 | 55 | LEFT INNER COVER | $60.49 | |||
| 334983 | 56 | LOWER UPRIGHT COVER | $63.49 | |||
 | 308523 | 57 | ROLLER ARM BUSHING | $19.99 | ||
| 334196 | 58 | RIGHT PEDAL ARM | $172.99 | |||
 | 291052 | 59 | AXLE BUSHING | $32.99 | ||
| 334989 | 60 | CRANK ARM COVER | $16.99 | |||
| 337988 | 61 | RIGHT UPPER BODY ARM | $108.99 | |||
 | 157600 | 62 | BUMPER | $1.99 | ||
| 338044 | 63A | RIGHT SENSOR ASSY | $65.49 | |||
 | 268411 | 64 | M6 WASHER | $0.99 | ||
| 316048 | 66 | LEFT PEDAL ARM COVER | $5.49 | |||
| 333643 | 67 | RIGHT OUTER COVER | $60.49 | |||
| 333642 | 68 | RIGHT INNER COVER | $60.49 | |||
| 338045 | 69A | LEFT SENSOR ASSY | $65.49 | |||
| 306646 | 70 | PIVOT ARM BUSHING | $29.99 | |||
| 334987 | 71 | DISC | $165.99 | |||
| 285643 | 72 | SMALL BEARING | $10.99 | |||
| 335143 | 73 | LEFT FRONT SHIELD | $191.49 | |||
| 334985 | 75 | SHIELD COVER | $134.49 | |||
| 333638 | 76 | LEFT REAR SHIELD | $102.99 | |||
| 333639 | 77 | RIGHT REAR SHIELD | $102.99 | |||
| 281559 | 78 | KEY | $2.49 | |||
 | 194653 | 79 | M6 ACORN NUT | $1.99 | ||
| 333645 | 80 | REAR UPRIGHT COVER | $104.99 | |||
 | 348636 | 81 | ROLLER ARM COVER | $42.99 | ||
| 306635 | 83 | PLASTIC SPACER | $3.49 | |||
| 240818 | 84 | M10 X 90MM SCREW | $22.99 | |||
| 275979 | 85 | M6 X 12MM HEX SCREW | $1.99 | |||
| 310999 | 86 | M10 X 58MM BOLT | $8.49 | |||
| 281156 | 88 | BELT ADJUSTMENT SCREW | $8.49 | |||
 | 208163 | 89 | M6 X 20MM HEX SCREW | $1.99 | ||
| 198497 | 90 | M10 X 55MM SCREW | $6.99 | |||
| 333644 | 91 | FRONT UPRIGHT COVER | $104.99 | |||
 | 153280 | 92 | BASE FOOT | $14.49 | ||
 | 168267 | 93 | FAN SCREW | $0.99 | ||
| 321268 | 94 | PEDAL SPRING | $3.49 | |||
 | 287202 | 95 | 16MM WAVE WASHER | $1.99 | ||
| 183870 | 96 | M8 X 35MM BUTTON BOLT | $2.49 | |||
| 306712 | 97 | MOTOR AXLE | $14.99 | |||
| 222789 | 98A | M8 X 32MM WASHER | $3.99 | |||
 | 261150 | 98B | M8 WASHER | $2.20 | ||
 | 275907 | 99 | M10 LOCKNUT,CRNK ARM CLMP | $4.49 | ||
| 223084 | 100 | M10 X 140MM BOLT | $14.99 | |||
 | 281150 | 101 | M6 X 20MM SHOULDER SCREW | $4.49 | ||
 | 256446 | 102 | M8 NUT | $0.99 | ||
 | 325993 | 103 | PEDAL PIN | $19.99 | ||
 | 013162 | 104B | CABLE TIE/BELLYPAN SCREW | $0.99 | ||
 | 195562 | 104C | M4 X 16MM SCREW | $1.99 | ||
 | 237612 | 105A | M8 X 16MM SCREW | $1.49 | ||
| 310520 | 105B | M8 X 16MM HEX SCREW | $2.49 | |||
 | 013423 | 106 | LATCH PLATE SCREW | $0.99 | ||
 | 125819 | 107 | PLASTIC STAND-OFF | $3.99 | ||
 | 014033 | 109 | WASHER | $1.49 | ||
 | 342275 | 112 | POWER CORD | $49.99 | ||
 | 186476 | 113 | DRIVE BELT | $49.99 | ||
 | 282411 | 114 | TRAY FAN | $119.99 | ||
| 303935 | 116 | M10 X 104MM SCREW | $13.49 | |||
 | 286527 | 117A | MUSHROOM FASTENER/SCREW | $2.49 | ||
| 303479 | 117B | COVER MOUNT SCREW | $3.99 | |||
| 334515 | 118 | CONTROL BOARD BRACKET | $22.49 | |||
 | 223809 | 119 | M10 X 75MM BOLT | $15.49 | ||
| 262341 | 121 | M6 X 12MM SCREW | $3.49 | |||
| 234325 | 122 | M8 STAR WASHER | $1.49 | |||
 | 013322 | 123 | SCREW | $0.99 | ||
 | 013576 | 124 | M4 X 16MM FLAT HEAD SCREW | $0.99 | ||
| 197037 | 125 | M6 X 12MM SCREW | $0.99 | |||
| 251831 | 127 | M4 X 22MM SCREW | $1.99 | |||
| 313138 | 128 | TABLET HOLDER SCREW | $1.49 | |||
 | 250868 | 129 | M8 X 23MM X 1.5MM WASHER | $3.49 | ||
 | 129004 | 132 | UPRIGHT GROMMET | $1.99 | ||
 | 306644 | 133 | CRANK ARM BUSHING | $35.99 | ||
| 316014 | 134 | RAMP SHIELD | $49.49 | |||
| 334962 | 135 | ROLLER ARM FLEX BRACKET | $25.49 | |||
| 315637 | 136 | PEDAL ARM FLEX BRACKET | $27.49 | |||
| 315632 | 137 | FLEX BRACKET COVER | $20.99 | |||
| 334957 | 138 | LEFT PEDAL BRACKET | $132.49 | |||
| 334960 | 139 | RIGHT PEDAL BRACKET | $132.49 | |||
| 333605 | 140 | FAN BRACKET | $46.49 | |||
| 249930 | 141 | M8 X 20MM SCREW | $2.99 | |||
| 014174 | 142 | M8 SPLIT WASHER | $1.99 | |||
| 155623 | 143 | CONSOLE GROUND WIRE | $3.99 | |||
| 339346 | 144 | SHORT SPACER | $19.99 | |||
| 346386 | 145 | SMALL SNAP RING | $23.99 | |||
| 101896 | # | 4″ WHITE WIRE,M/F | $3.49 | |||
| 307216 | # | 50″ WIRE, LIFT MOTOR | $61.49 | |||
 | 140069 | # | SNAP RING PLIERS | $12.99 | ||
| 334186 | # | FAN WIRE HARNESS | $40.99 | |||
| 331242 | # | GROMMET | $6.49 | |||
| 116566 | # | 15 1/2″ CABLE TIE | $0.99 | |||
| 132315 | # | WIRE TIE | $3.49 | |||
| 324737 | # | 20″ CNTRLR/RESIST WIRE | $30.49 | |||
| 297256 | # | 6MM ALLEN WRENCH | $13.49 | |||
| 215823 | # | AUDIO WIRE | $11.99 | |||
| 297255 | # | 5MM ALLEN WRENCH | $7.49 | |||
| 146119 | # | FLOOR MAT | $79.99 | |||
 | 112083 | # | 8″ BLUE WIRE, 2F | $4.49 | ||
| 307217 | # | 50″ WIRE HRNS, LIFT MOTOR | $20.99 | |||
| 142711 | # | GROUND WIRE | $2.49 | |||
| 334244 | # | DECAL, RIGHT RAMP ANGLE | $30.49 | |||
| 334243 | # | DECAL, LEFT RAMP ANGLE | $30.49 | |||
| 016057 | # | 8″ CABLE TIE | $2.99 | |||
| 334241 | # | DECAL, PEDAL ADJ | $25.49 | |||
| 323876 | # | DECAL, GENERAL WARING | $3.99 | |||
 | 304974 | # | 4MM ALLEN WRENCH | $4.49 | ||
 | 104838 | # | LUBE, GREASE | $8.49 | ||
| 166909 | # | DECAL, SITE WARNING | $2.49 | |||
| 116926 | # | RELEASABLE TIE | $0.99 |
